Description
Product Description
The 2.0 Performance Series Shocks delivers race-dominating performance in a hassle free bolt-on package. Their heat-reducing design includes a metal-impacted aluminum shock body that dissipates heat faster than conventional steel. Inside the Internal Floating Piston (IFP) separates shock oil from a high-pressure nitrogen gas chamber that provides a predicable ride quality capable of handling the roughest road conditions. Combine these new technologies with a competitive price for a winning combination.Shock Absorber; Performance Series; Hydraulic/ Nitrogen Gas Charged Mono Tube; With External Reservoir; 1 Year Factory Warranty; Non Adjustable; Without Boots; Single
Features & Benefits
- Packed With 35 Years Of Race Winning Technology
- Performance Tuned For Vehicle Specific Application
- Aluminum Body Dissipates Heat Faster Than Steel. Black Anodized CNC Machined Aluminum Components
- External Reservoir System Dissipates Heat Fast
- 100 Percent Serviceable And Tunable For Longer Lifespan
- Nitrile Bushings Allow For Incread Articulation
- Redundant Sealing System, Long Lasting Performance
- Limited 1 Year Factory And 90 Day Valving Warranty
Attributes
- Type: Hydraulic/ Nitrogen Gas Charged
- With Coil Spring: No
- Extended Length (IN): 29.45 Inch
- Compressed Length (IN): 17.35 Inch
- Upper Mounting Style: Eyelet
- Lower Mounting Style: Eyelet
- Adjustable Valving: No
- Quantity: Single
- Universality: Vehicle Specific
- Internal Design: Monotube
- Body Color: Silver
- Rod Diameter (IN): 5/8 Inch
- Valving Type: Application Specific Valving
- Rod Material: Steel
- Body Material: Aluminum
- With Reservoir: Yes
- Includes Dust Shield: No
- Includes Hardware: Yes
- Includes Boot: No
- Estimated Install Time (Hours): 0.5
Installation Instructions
- 605-01-053_REV_C.pdf
Technical Bulletins
- FOX_TRUCK_2.0PSReservoir_Exploded_A.pdf
- FOX_TRUCK_2.0PSReservoir_Exploded_A.pdf
- FOX_TRUCK_2.0PSReservoir_Exploded_A.pdf
- 605-01-053_REV_C.pdf
Specifications:
| Prop 65 Y/N | Y |
| Body Diameter (in) | 2 |
| Label Name | 94-On Dodge 2500/3500 Rear, PS, 2.0, R/R, 12.1″, 2-3.5″ Lift |
| Fox Catalog | TRUCK |
| Extended Length (in) | 29.52 |
| Compressed Length (in) | 17.40 |
| California Proposition 65 | ! WARNING: Cancer and Reproductive Harm – www.P65Warnings.ca.gov |
| Bottom Mount (p/n) | 213-28-001-B |
| Bottom Mount | ES7 |
| Body Material | Aluminum |
| Travel (in) | 12.12 |
| Type | Smooth Body |
| Series | Performance |
| Reservoir Type | Remote |
| Top Mount (p/n) | 213-28-001-B |
| Top Mount | ES7 |
| Title | PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK |
| Description_DES | PERFORMANCE SERIES 2.0 SMOOTH BODY RESERVOIR SHOCK |
| Description_LAB | 94-On Dodge 2500/3500 Rear, PS, 2.0, R/R, 12.1″, 2-3.5″ Lift |
| Description_SHO | 2.0 Shock |
| Description_ASC | Increase your vehicle’s off-road capability by extending drop-out travel in most applications. Experience on-road comfort with performance-minded shock valving for a connected ride with less vehicle sway. Tuned specifically for your vehicle’s application._x000D__x000D_Consistent and fade-resistant performance due to high-quality materials: aluminum bodies, race-developed main piston, and a true internal floating piston (IFP) to separate gas and oil._x000D__x000D_Built-to-last, torture-tested and race-proven to give a lifetime of great rides. FOX products are built from aluminum, dissipating heat four times better than conventional materials. All FOX shocks are fully serviceable and resistant to corrosion and harsh environments. |
| Description_INV | FOX 2.0 PERFORMANCE SERIES RESI SHOCK |
| Description_EXT | Application specific valving to maximize performance. |
| Description_FAB | Includes Aluminum Reservoir Clamp |
| Description_FAB | Performance Tuned For Vehicle Specific Application |
| Description_FAB | Aluminum Body Dissipates Heat Faster Than Steel |
| Description_FAB | External Reservoir System Dissipates Heat Fast |
| Description_FAB | Black Anodized CNC Machined Aluminum Components |
| Description_MKT | FOX Performance Series shocks contain the latest in shock technology to transform the performance of your Truck or SUV. They use our race-proven damping control to provide a comfortable on-road ride and predictable off-road handling in even the toughest conditions. |
| Description_DEF | Suspension Shock Absorber |
